37" Production Two Stations Wide Belt Sander 50-530 T4

Regular price $0.00

Shipping calculated at checkout

SKU: 50-530T4


  • Two working stations offering optimum sanding
  • 1st Station: light calibrating roller up to 0.5 mm with a hard-spiral grooved rubber roller
  • 2nd Station: “COMBI STATION” with a smaller roller and a felt platen. Maximum capacity of 0,1 mm
  • Automatic braking device on motor pulley unit in case of either breakage or run off of the sanding belt
  • Pneumatic sanding belts tracking mechanism
  • Air pressure safety switch preventing machine start-up without tension on the sanding belts
  • Motorized table height movement with accurate adjustment.
  • Amperage / Load meter on sanding belts to monitor belt wear
  • Panic bar; automatic shut-off when pressed in case of emergency

Technical Specification

Main motor power

20 HP - 600V - 3 ph - 20 A

Feed motor

1 HP

Table lift motor

1/4 HP

Max. working width

36,5" ( 927 mm )

Max. height

5,91" ( 150 mm )

Abrasive belt dimensions

37" x 75" ( 940 X 1905 mm )

Feed speed (variable)

15 to 49 ft./min

Quantity dust outlets

6 X Ø 5"

Approx. Weight

2645 lb ( 1200 kg )
